Irregular Roof Area Calculator

Draw the outline of a roof to get its flat footprint area, then enter the pitch to get the sloped roof surface area.

Irregular Roof Area Calculator

Draw your roof outline to calculate total roof area accurately.

Projected Roof Area: —

To use the tool, choose feet or metres, click the corners of the roof outline in order around the edge, enter the pitch if you know it, and press Calculate. Reset clears the canvas, and the buttons next to it export the sketch as a PNG or JSON file or print it.

How the calculator works

Projected area from the outline

The tool applies the shoelace formula to the corners you click. The result is the projected roof area, which is the flat area you would see from directly above.

Projected Area = ½ × |Σ (xᵢ × yᵢ₊₁ − xᵢ₊₁ × yᵢ)|

Where:

  • xᵢ and yᵢ are the coordinates of corner i, in drawing units
  • The last corner joins back to the first
  • The drawing scale is fixed at 10 screen pixels per unit, so the edge labels and the area come out in feet or metres, whichever you select

The canvas is 420 pixels tall, which is 42 units, and its width follows your screen. A roof that is larger than the canvas will not fit in one sketch, so calculate it in parts and add the results. Click the corners in order around the outline and do not cross the lines, because a crossed outline gives a wrong area.

Sloped surface area from the pitch

If you enter a pitch, written as the rise per 12 units of run, the calculator also shows the sloped surface area:

Slope Factor = √(1 + (Rise ÷ 12)²)


Roof Surface Area = Projected Area × Slope Factor

A steeper roof has a larger factor. A pitch of 4/12 gives 1.054, 6/12 gives 1.118, 8/12 gives 1.202 and 12/12 gives 1.414. A roofing guide lists the same multipliers.

What the tool does not do

The calculator applies one pitch to the whole outline. It does not add overhangs, waste, hips or valleys as separate items, and because you place the corners by clicking, the sketch is only as accurate as your clicks. Use it to sketch and compare shapes, and use measured dimensions when you need exact figures.

Worked examples

A pitch adjustment

A roof has a projected area of 1,000 ft² and a pitch of 6/12. The slope factor is √(1 + 0.5²) = 1.118. Roof surface area = 1,000 × 1.118 = 1,118 ft², which is 11.18 roofing squares, since one square is 100 ft².

An L-shaped roof

Split the footprint into two rectangles: 40 ft × 25 ft = 1,000 ft² and 20 ft × 15 ft = 300 ft², so the projected area is 1,300 ft². At a pitch of 8/12 the factor is √(1 + 0.667²) = 1.2019, and the surface area is 1,300 × 1.2019 = 1,562.4 ft², or 15.6 squares.

A metric roof

A footprint of 120 m² at 6/12 has a surface area of 120 × 1.118 = 134.2 m².

Including the overhang

A house measures 30 ft by 40 ft, which is 1,200 ft². If the roof overhangs by 1 ft on every side, the roof outline is 32 ft by 42 ft, which is 1,344 ft². At 6/12 the surface area is 1,344 × 1.118 = 1,502.6 ft², against 1,341.6 ft² if you measure only the walls. The overhang adds about 161 ft², so draw the outline at the edge of the roof, not at the wall.

Two pitches on one roof

A main section has a projected area of 800 ft² at 6/12, and an addition has 400 ft² at 9/12. The main section is 800 × 1.118 = 894.4 ft² and the addition is 400 × 1.25 = 500 ft², so the total is 1,394.4 ft². Because the tool applies one pitch to an outline, run it once for each section and add the two results.

Measuring a real roof

A roofing guide gives these steps: measure each roof plane separately, including dormers and additions, multiply the length by the width for each plane, add the planes together, and divide by 100 to get roofing squares. If every plane has the same pitch, you can multiply the whole footprint by one slope factor, hips and valleys included. If the pitches differ, calculate each section on its own.

To find the pitch, measure the rise over a run of 12 inches with a level and a tape, or read it from the plans. Do not use the floor area of the house as the roof area, because it leaves out the overhang and the slope.

Irregular Roof Area calculator- How to calculate Irregular Roof Area

From roof area to the material you buy

Roof area is not the same as the amount of material to order. A roofing guide suggests about 10 percent extra for a simple gable roof, 10 to 15 percent for a hip roof, and 15 to 20 percent for a complex roof with several valleys, because cuts around hips, valleys, chimneys and skylights leave offcuts. The right figure depends on the roofing type and the layout, so ask your supplier. For the L-shaped roof above, 1,562.4 ft² plus 15 percent is 1,796.8 ft², which is about 18 squares.

Common mistakes

  • Using the floor area of the house, which misses the overhang and the slope
  • Forgetting dormers, extensions and porches
  • Applying one pitch to sections that have different pitches
  • Mixing feet and metres between the sketch and the pitch calculation

For the cost of a new roof, see the roof replacement cost calculator, the metal roof cost calculator and the asphalt shingle roof cost calculator. For shapes and slopes, see the gable area calculator and the triangle slope, grade and pitch calculator.

FAQs

How do I calculate the area of an irregular roof?

Split the roof into planes, find the area of each, and add them, or draw the outline in the calculator. Then multiply by the slope factor for the pitch to get the sloped surface area.

What is the difference between projected roof area and surface area?

Projected area is the flat footprint seen from above. Surface area is the real area of the sloped roof, and is always larger. Surface area = projected area × √(1 + (rise ÷ 12)²).

How do I turn a pitch into a slope factor?

Divide the rise by 12, square it, add 1, and take the square root. For a 6/12 pitch the factor is √(1 + 0.25) = 1.118.

Does the calculator include the overhang and waste?

No. Draw the outline at the edge of the roof to include the overhang. Waste is not included, and a roofing guide suggests about 10 to 20 percent depending on the complexity of the roof.

Can I use it for a roof with different pitches?

The tool applies one pitch to the whole outline. For a roof with several pitches, calculate each section on its own and add the results.

How many roofing squares is my roof?

Divide the roof surface area in square feet by 100. A roof of 1,118 ft² is 11.18 squares.

How large a roof can I draw?

The scale is fixed at 10 pixels per unit and the canvas is 420 pixels tall, so the drawing is about 42 units high. For a larger roof, calculate it in parts.
