Hollow Cylinder (Tube) Surface Area Calculator
Inner, outer, end and total surface area of a hollow cylinder, round tube, rod sleeve or square tube.
Starting values: the radii mode opens with an outer radius of 5, an inner radius of 4 and a length of 20. That gives an outer surface of 628.32, an inner surface of 502.65, ends of 56.55 and a total of 1,187.52. The wall mode opens with an outer diameter of 10 and a wall of 1, which is the same tube, and the square tube mode with a side of 5, a wall of 0.3 and a length of 100.
Hollow cylinder formulas
A hollow cylinder has four surfaces: the outside curved face, the inside curved face and two flat ring-shaped ends.
Outer surface = 2πRL
Inner surface = 2πrL
Both ends = 2 × π(R² − r²)
Total area = 2π(R + r)L + 2π(R² − r²)
Where:
- R = outer radius
- r = inner radius
- L = length of the tube
- π(R² − r²) = area of one ring-shaped end
With R = 5, r = 4 and L = 20:
Outer = 2π × 5 × 20 = 628.32, inner = 2π × 4 × 20 = 502.65, ends = 2π × (25 − 16) = 56.55, total = 1,187.52
The two curved faces make up about 95 percent of the total here, because the tube is long compared with its wall. A short, thick ring would have a much larger share in its ends.
From outer diameter and wall thickness
Drawings often give the outer diameter D and the wall thickness t rather than two radii. The calculator converts them with R = D ÷ 2 and r = D ÷ 2 − t, then applies the same formulas.
Suppose a sleeve has an outer diameter of 50 mm, a wall of 5 mm and a length of 300 mm. Then R = 25 mm and r = 20 mm:
Outer = 2π × 25 × 300 = 47,123.89 mm², inner = 2π × 20 × 300 = 37,699.11 mm², ends = 2π × (625 − 400) = 1,413.72 mm²
The total is 86,236.72 mm², which is 862.37 cm² because 100 mm² equals 1 cm².
Square tube
A square tube has an outer side a, a wall thickness t and an inner side a − 2t.
Outer = 4aL, Inner = 4(a − 2t)L, Ends = 2 × (a² − (a − 2t)²)
For a = 5, t = 0.3 and L = 100, the inner side is 4.4:
Outer = 4 × 5 × 100 = 2,000, inner = 4 × 4.4 × 100 = 1,760, ends = 2 × (25 − 19.36) = 11.28, total = 3,771.28
These formulas assume sharp inside and outside corners. A real rolled or extruded tube has rounded corners, which changes the area by a small amount, so treat the result as the clean geometric value.
Which surface do you need?
- Painting or wrapping the outside only: use the outer surface.
- Lining or coating the bore: use the inner surface.
- A tube with open ends where the ends are not exposed: add the outer and inner surfaces and leave out the end rings.
- A finished part treated on every face: use the total.
The radii mode lists the outer, inner, end and total areas separately, and the other two modes list the total, outer and inner areas.
Hollow cylinder or pipe?
A pipe is a hollow cylinder, but a pipe run is normally specified by its outside diameter and measured over a long length with the ends ignored. If that is your job, the pipe surface area calculator works in those terms.
Common mistakes
- Swapping the radii. The outer radius must be larger, and the calculator warns you if it is not.
- Entering a wall thickness of half the outer diameter or more, which leaves no bore.
- Mixing units, such as a diameter in mm and a length in m.
- Using the total area when the ends are not part of the job.
What this calculator does not do
It does not give volume or weight, and it does not handle tapered bores, off-centre holes, chamfers or rounded tube corners. The result is the geometric area, so allow for coating coverage and waste separately, using the figures from the product you are applying.
Related: Irregular Cylinder Surface Area Calculator.
Thin wall or thick wall: where the area sits
The share of the total taken by the end rings depends on the wall. Keep R = 5 and L = 20 but make the wall very thin, with r = 4.9. The outer surface is 628.32, the inner surface is 615.75 and the ends are only 2π × (25 − 24.01) = 6.22, so the total is 1,250.29 and the ends are about half a percent of it.
Now take a short thick ring with R = 5, r = 1 and L = 2. The outer surface is 62.83, the inner surface is 12.57 and the ends are 2π × 24 = 150.80, so the total is 226.19 and the ends are about two thirds of it. For short, thick parts do not leave the ends out.
Frequently asked questions
What is the formula for the surface area of a hollow cylinder?
The total is 2π(R + r)L + 2π(R² − r²), where R is the outer radius, r the inner radius and L the length. It is the outside curved face, the inside curved face and the two ring-shaped ends added together.
How do I find the inner radius from the wall thickness?
Subtract the wall thickness from the outer radius: r = R − t. If you have the outer diameter D instead, use r = D ÷ 2 − t, or choose the outer diameter and wall mode and let the calculator do it.
Do I include the ends of the tube?
Only if they are exposed to the job. The total includes both ring-shaped ends. For a long open tube you often want just the outer surface, the inner surface or the two added together.
Can I calculate the surface area of a square tube?
Yes. Use the square tube mode with the outer side, the wall thickness and the length. The inner side is the outer side minus twice the wall thickness.
