Cone Surface Area Calculator

Enter the base radius with the height or slant height, or the diameter with the height, to get the total, lateral (curved) and base area of a right circular cone. The tool also returns the slant height or the height you did not supply.

Surface Area Calculators

Cone Surface Area Calculator

Total, lateral (curved) and base area of a right circular cone from radius and height or slant height.

Cone surface area formulas

A right circular cone has a circular base and a curved side that rises to a point directly above the center. Its surface area is the base plus the curved side.

Base area B = π × r²
Lateral area L = π × r × s
Total surface area A = π × r × (r + s)
Slant height s = √(r² + h²)

Where:

  • r = radius of the base (half the diameter).
  • h = vertical height from the base to the tip.
  • s = slant height, measured along the curved side from the rim to the tip.

The three input modes

  • Radius and height: returns total, lateral and base area plus the slant height.
  • Radius and slant height: returns total and lateral area plus the height, and checks that the slant height is longer than the radius.
  • Diameter and height: halves the diameter, then returns total and lateral area plus the slant height.

Worked examples

Example 1: radius 3, height 4

s = √(3² + 4²) = √25 = 5
Base = π × 9 = 28.2743
Lateral = π × 3 × 5 = 47.1239
Total = π × 3 × (3 + 5) = 75.3982

These are the starting values in the tool. Total equals lateral plus base: 47.1239 + 28.2743.

Example 2: radius 5, height 12

s = √(25 + 144) = 13
Base = π × 25 = 78.5398
Lateral = π × 5 × 13 = 204.2035
Total = π × 5 × 18 = 282.7433

Example 3: radius 3, slant height 5

h = √(s² − r²) = √(25 − 9) = 4
Lateral = 47.1239, Total = 75.3982

It gives the same cone as example 1, reached from different measurements.

Example 4: diameter 12, height 8

r = 12 ÷ 2 = 6
s = √(36 + 64) = 10
Lateral = π × 6 × 10 = 188.4956
Total = π × 6 × 16 = 301.5929

Working backwards from an area

If you know an area and the radius, you can find the slant height by rearranging the formulas, then use the radius-and-slant mode to check it.

From lateral area: s = L ÷ (π × r)
From total area: s = A ÷ (π × r) − r
Check: A = 75.3982, r = 3 → s = 75.3982 ÷ 9.4248 − 3 = 5

Lateral area or total area?

Use the lateral area when only the curved side matters, such as a conical roof, a funnel, a lampshade or a paper party hat. Use the total when the base is also covered, as with a solid cone you want to paint or wrap.

Example: a conical roof

r = 4 m, h = 3 m → s = 5 m
Lateral = π × 4 × 5 = 62.83 m²

That is the surface to cover, not the material to buy. Overhang, overlap and waste depend on the roofing or sheeting material, so add an allowance from the product instructions.

Making a paper cone

Unrolled, the curved side of a cone is a sector of a circle whose radius equals the slant height. The sector angle comes from the ratio of the base radius to the slant height.

Sector angle = 360° × r ÷ s
r = 4, s = 10 → angle = 360 × 4 ÷ 10 = 144°
Sector area = (144 ÷ 360) × π × 10² = 125.66, equal to π × 4 × 10

The match between the sector area and πrs is why the lateral formula has that form.

Units and limits

Units

Use one length unit for every input. The area comes out in that unit squared, so centimeters give square centimeters. The tool uses the full value of π, not 3.14, so its results can differ in the last digits from a hand calculation.

What the tool does not cover

It handles right circular cones only. A truncated cone (frustum) and an oblique cone, whose tip is not above the center, need different formulas.

Frequently asked questions

How do I find a cone surface area from the diameter?

Halve the diameter to get the radius, then use A = πr(r + s). A diameter of 12 and a height of 8 give r = 6, s = 10 and a total area of 301.5929.

What is the difference between slant height and height?

Height is the straight vertical distance from the base to the tip. Slant height is measured along the curved side and is longer: s = √(r² + h²).

What is the difference between lateral and total surface area?

Lateral area is the curved side only, πrs. Total area adds the circular base, πr², so total = πrs + πr² = πr(r + s).

Why does the tool say the slant height must be longer than the radius?

In a right cone the slant height is the hypotenuse of a triangle with the radius and the height as its other sides, so it must exceed the radius.

Can I find the slant height from an area?

Yes. From the lateral area use s = L ÷ (πr), and from the total area use s = A ÷ (πr) − r.

Does the calculator work for a frustum?

No. A frustum is a cone with its tip cut off and has two radii, so it needs its own formula.
