This regular polygon area calculator finds the area of any regular polygon from the number of sides and one measurement: the side, the apothem, the circumradius, the perimeter or the area. It also gives the interior and exterior angles, the sum of the interior angles, the number of diagonals, and the areas of the inscribed and circumscribed circles.
The starting example is a hexagon with a 6 cm side, which has an area of 93.5307 cm².
How is the area of a regular polygon calculated?
There are several equal forms. The simplest is half the apothem times the perimeter, which works for any number of sides. The side-only form uses cotangent.
Area = ½ × Apothem × Perimeter
Area = ¼ × n × Side² × cot(180° ÷ n)
Area = n × Apothem² × tan(180° ÷ n)
Area = ½ × n × Circumradius² × sin(360° ÷ n)
Perimeter = n × Side
Where n is the number of sides. The apothem is the distance from the centre to the middle of a side, and the circumradius is the distance from the centre to a corner. The tool converts whichever measurement you give into the side first, using side = 2 × apothem × tan(180° ÷ n) or 2 × circumradius × sin(180° ÷ n).
Worked example: a hexagon with a 6 cm side
Worked by hand, the same hexagon has a perimeter of 36 cm, an apothem of 3√3, about 5.196 cm, and an area of 54√3, about 93.53 cm². The tool shows the unrounded values.
Perimeter = 6 × 6 = 36 cm
Apothem = 5.1962 cm
Area = ½ × 5.1962 × 36 = 93.5307 cm²
Circumradius = 6 cm
A regular hexagon’s circumradius equals its side. The incircle area is 84.823 cm² and the circumcircle area is 113.0973 cm². In other units the area is 14.4973 in² or 0.0094 m².
What are the interior and exterior angles?
The interior angle is (n − 2) ÷ n × 180° and the exterior angle is 360° ÷ n. The angles are 108° and 72° for a pentagon, and the table lists 108° and 72° for a pentagon, 120° and 60° for a hexagon, 135° and 45° for an octagon, and 128.57° and 51.43° for a heptagon.
Interior angle = (n − 2) × 180° ÷ n
Exterior angle = 360° ÷ n
Sum of interior angles = (n − 2) × 180°
Diagonals = n × (n − 3) ÷ 2
The tool matches that table. A heptagon shows 128.5714° and 51.4286°, with a sum of 900° and 14 diagonals. A hexagon has a sum of 720° and 9 diagonals, and an octagon has 1,080° and 20.
Worked examples for different jobs
Worked examples
A regular octagon from its side
An octagon with a side of 1 has an area of 2 × (1 + √2), which is 4.8284. Its apothem is 1.2071 and its circumradius is 1.3066.
An octagon from its circumradius
With a circumradius of 10 the area is ½ × 8 × 100 × sin 45°, which is 282.8427.
Working backwards from an area
An octagon of area 100 has an apothem of 5.4934, a perimeter of 36.4072 and a side of 4.5509. Choose area as the known measurement.
A figure from its perimeter
An octagonal frame with a 60 unit perimeter has a side of 7.5 and an area of 271.599.
What the calculator leaves out
It covers regular polygons only, with equal sides and equal angles. Irregular shapes need splitting into triangles or a coordinate method. The number of sides must be a whole number from 3 to 10,000. All lengths must share one unit, and an area you enter must be in that unit squared.
Frequently asked questions
What is the formula for the area of a regular polygon?
Half the apothem times the perimeter. A hexagon with a 6 cm side has an apothem of 5.1962 and a perimeter of 36, so the area is 93.5307 cm².
How do I find the area of a regular polygon from the side?
Use ¼ × n × side² × cot(180° ÷ n). For a hexagon with a side of 6 that gives 93.5307.
What is the interior angle of a regular polygon?
(n − 2) × 180° ÷ n. A hexagon has 120°, an octagon 135° and a heptagon 128.5714°.
How many diagonals does a regular polygon have?
n × (n − 3) ÷ 2. A hexagon has 9, a heptagon 14 and an octagon 20.
What is the apothem of a regular polygon?
The distance from the centre to the middle of a side. A hexagon with a side of 6 has an apothem of 5.1962.
Why is my answer slightly different from a textbook?
Textbook inputs are often rounded. The pentagon with apothem 5.5 gives 109.8896 here, while the textbook’s 110 uses a rounded side of 8.
